Applications: |
Intra-city distribution, Parcel / Logistics, Market load, Fruits and vegetables, Poultry |
Engine: |
H-series, 4-cylinder diesel engine with in-line fuel injection pump (FIP) |
Power: |
120 HP @ 2400 RPM |
Torque: |
415 Nm @1600 RPM |
Clutch: |
310 mm diameter, single dry plate, push-type with hydraulic actuation and clutch booster |
Transmission: |
6-speed overdrive gear box, FGR- 6.93:1 |
Suspension: |
Parabolic leaf springs with shock absorbers |
Cabin: |
Day cabin with hydraulic tilt mechanism |
Tyre: |
8.25X16 – 14 PR |
Max speed: |
99 kmph |
Gradeability: |
25.5% |
GVW: |
9600 kgs |
Wheelbase: |
3440 | 3940 | 4540 |
Loading span: |
14 | 17 | 20 |
