| Applications: | Market load, Cement , Ores & Minerals ,Steel |
|---|---|
| Engine: | HA6ETI3U |
| Power: | 180 hp @ 2400 rpm |
| Torque: | 660 Nm @ 1500 - 1700 rpm |
| Clutch: | 380 mm dia , Ceramic clutch disc |
| Transmission: | 9 speed synchromesh FGR 8.83:1 |
| Suspension: | Uprated Semi elliptic multileaf |
| Tyre: | 11R x 20 Radial tyres |
| Max speed: | 67 kmph |
| Gradeability: | 15. 3% |
| GVW: | 37T |
| Wheelbase: | 6600 mm |
