Applications: |
Surface Transportation Blue Metal, Sand , Coal or other bulk Materials |
Engine: |
H series - BS3 Tubocharged intercooled |
Power: |
180 HP @ 2400 rpm |
Torque: |
660 Nm @ 1500-1700 rpm |
Clutch: |
Axial type 381 mm dia with ceramic disc and actuated by clutch booster |
Transmission: |
9 Speed GB - FGR: 8.83 & Crawler : 12.73. |
Suspension: |
Semi-Elliptic Multi Leaf in front and Non - Reactive suspension at rear |
Cabin: |
G 45 Cowl / Cabin |
Tyre: |
10.00 x 20 - 16 PR |
Max speed: |
78 Kmph |
Gradeability: |
29.7% in CWG |
GVW: |
31000 kgs |
Wheelbase: |
5250 |
Body Capacity: |
8.5 cu.m |
