Applications: | Stone , marble , refuellers |
---|---|
Engine: | H Series 6ETI3K turbocharged with inline FIP |
Power: | 160 hp @ 2400 rpm |
Torque: | 550 Nm @ 1500 - 1700 rpm |
Clutch: | Single plate dry plate, with clutch booster, 380 mm facing dia |
Transmission: | ZF S636; FGR 8.97:1 |
Suspension: | Semi elliptical laminated multileaf |
Cabin: | Factory built G45 cowl |
Tyre: | 10.00 x 20 - 16 PR Nylon ply - (radial ply optional) |
Max speed: | 79 kmph |
Gradeability: | 18.54% |
GVW: | 25000 kgs |
Wheelbase: | 4902 mm |
Loading span: | 23.5 ft |
